Atmega16 is an 8-bit controller based on AVR advanced RISC (Reduced Instruction Set Computing) architecture. AVR is family of microcontrollers developed by Atmel in 1996.
It is a single chip computer that comes with CPU, ROM, RAM, EEPROM, Timers, Counters, ADC and four 8-bit ports called PORTA, PORTB, PORTC, PORTD where each port consists of 8 I/O pins.
Atmega16 has built-in registers that are used to make a connection between CPU and external peripherals devices. CPU has no direct connection with external devices. It can take input by reading registers and give output by writing registers.
Atmega16 comes with two 8-bit timers and one 16-bit timer. All these timers can be used as counters when they are optimized to count the external signal.
Most of the necessary peripherals required to run automatic functions are incorporated in this device like ADC (analog to digital converter), Analog comparator, USART, SPI, which make it economical as compared to a microprocessor that requires external peripheral to perform various functions.
Atmega16 comes with 1KB of static RAM which is a volatile memory i.e stores information for short period of time and highly depends on the constant power supply. Whereas 16KB of flash memory, also known as ROM, is also incorporated in the device which is non-volatile in nature and can store information for long period of time and doesn’t lose any information when the power supply is disconnected.
Atmega16 comes with 1KB of static RAM which is a volatile memory i.e stores information for short period of time and highly depends on the constant power supply. Whereas 16KB of flash memory, also known as ROM, is also incorporated in the device which is non-volatile in nature and can store information for long period of time and doesn’t lose any information when the power supply is disconnected.
Atmega16 is a 40-pin low power microcontroller which is developed using CMOS technology.
CMOS is an advanced technology which is mainly used for developing integrated circuits. It comes with low power consumption and high noise immunity.
CPU is like a brain of the controller which helps in executing a number of instructions. It can handle interrupts, perform calculations and control peripherals with the help of registers. Atmega16 comes with two buses called instruction bus and data bus. The CPU reads the instructions in the instruction bus while data bus is used to read or write the corresponding data. The CPU mainly consists of the program counter, general purpose registers, stack pointer, instruction register and an instruction decoder.
The controller program is stored in ROM, also known as non-volatile programmable flash memory. The flash memory comes with a resolution of at least 10,000 write/erase cycles. Flash memory is mainly divided into two parts known as Application flash section and booth flash section. Program of the controller is stored in the applications flash section. While booth flash section is optimized to work directly when the controller is powered up.
The SRAM (static random access memory) is used for storing information temporarily and comes with 8-bit registers. This is just like a regular computer RAM which is used to supply data through the runtime.
The EEPROM (Electronically Erasable Read Only Memory) is non-volatile memory used as a long time storage. It has no involvement in executing the main program. It is used for storing the configuration of the system and device parameters which continues to work in the reset of the application processor. EEPROM comes with a limited write cycle up to 100,000 while read cycles are unlimited. While using EEPROM, write minimum instructions as per requirement, so you can get benefit from this memory for a longer time.
The interrupt is used for an emergency which puts the main function on hold and executes the necessary instructions at that time. Once the interrupt is called and executed the code switches back to the main program.
Digital I/O modules are used to set a digital communication between the controller and external devices. While analog I/O modules are used for transferring analog information. Analog comparators and ADC fall under the category of analog I/O modules.
Timers are used for calculating the internal signal within the controller. Atmega16 comes with two 8-bit timers and one 16-bit timer. All these timers work as a counter when they are optimized for external signals.
The watchdog timer is a remarkable addition in this controller which is used to generate the interrupt and reset the timer. It comes with 128kHz distinct CLK source.
Atmega16 comes with USART and SPI units that are used for developing serial communication with the external devices.
