R307 Finger print sensor

  • Fast Shipping

    Receive products in amazing time
  • Easy Returns

    Return policy that lets you shop at ease
  • Always Authentic

    We only sell 100% authentic products
  • Secure Shopping

    Your data is always protected

1,750.00Br

Highlights

  • R307 Optical Fingerprint Reader Module
  • Type: Optical
  • Backlight: Blue
  • Interface: USB2.0/UART(TTL logical level)
  • RS232 Communication Baud Rate: 9600BPS~115200BPS changeable
  • Verification Speed: 0.1 sec
  • Scanning Speed: 0.2 sec
  • Character File Size: 256 bytes
  • Template Size:512 bytes
  • Storage Capacity: 1000
  • Security Level: 5 (1,2,3,4,5(highest)
  • FRR (False Rejection Ratio): ≤1%
  • FAR (False Acceptance Ratio): ≤0.0001%
  • Resolution: 500 DPI
  • Voltage: DC 4.2-6V
  • Working Current: 50mA (Typical)
  • Peak Current: 75mA
  • Matching Method: 1 : N
  • Operating Temperature: -20-50 °
  • Image Capture Surface: 1.5×1.1mm
  • Overall Size: 4.5×2.4x2cm

Description

  • R307 Optical Fingerprint Reader Module
  • Integrated image collecting and algorithm chip together, ALL-in-One
  • Fingerprint reader can conduct secondary development, can be embedded into a variety of end products.
  • Users can conduct secondary development, can be embedded into a variety of end products, such as: access control, attendance, safety deposit box, car door locks
  • Low power consumption, low cost, small size, excellent performance
  • Professional optical technology, precise module manufacturing technics
  • Good image processing capabilities, can successfully capture image up to resolution 500 dpi
