Name: BC109 NPN Transistor
SKU: 13351
Price: 15.00 ETB
Availability: InStock

BC109 NPN Transistor

Br 15.00

The BC109 is a general-purpose NPN bipolar junction transistor designed for switching and amplification in low-power applications.
Type Designator: BC109
Material of Transistor: Si
Polarity: NPN
Max Collector Current(I_C): 100mA
Max Collector-Emitter Voltage (V_CE): 20V
Max Collector-Base Voltage (V_CB): 30V
Max Emitter-Base Voltage (VBE): 5V
Max Collector Dissipation (Pc): 0.3W
Max Transition Frequency (fT): 100 MHz
Minimum & Maximum DC Current Gain (h_FE): 200 to 800
Package: TO-92

BC109 NPN General Purpose Transistor TO-92 (20V, 0.1A)
PNP Complementary: PNP Complementary of BC109 is BC179
The exact match transistor for BC109 is BC108. BC107 will also work but the only difference is its maximum DC current gain is 450 but in most cases, it will not make a big difference. Other nearest possible substitutes are A158C, BCY65X. If you can’t find these equivalents then you can also try the TO-92 Plastic package equivalents which are BC546, BC547, BC548, BC549, BC560.
