Name: DC Voltage Sensor Module
SKU: 8078
Price: 650.00 ETB
Availability: InStock

DC Voltage Sensor Module

Br 650.00

Voltage Sensor is a precise low-cost sensor for measuring voltage. It is based on the principle of resistive voltage divider design. It can make the red terminal connector input voltage to 5 times smaller.
Analog input voltages up to 5V
The voltage detection module input voltage not greater than 5Vx5=25V
Output Interface : connected 5/3.3V, – connected GND, s connected Aduino AD pins
DC input interface : red terminal positive with VCC, negative with GND
The Voltage Detection Sensor Module 25V is a simple yet highly effective solution for extending the voltage sensing capabilities of microcontrollers such as Arduino. Using a resistive voltage divider, it safely scales down input voltages up to 25V (16.5V for 3.3V systems) into a measurable range compatible with standard ADC pins. With a resolution of 0.00489V, it ensures precise monitoring for power supplies, batteries, and other electronic circuits.
Featuring screw terminal inputs for secure wiring and a convenient 3P connector for Arduino expansion boards, this module is easy to integrate into your projects. It can also be paired with IICLCD1602 LCDs for live voltage display, making it a versatile tool for prototyping and real-world applications

DC Voltage Sensor Module
