Name: Operational Amplifier LF353P
SKU: 13998
Price: 50.00 ETB
Availability: InStock

Operational Amplifier LF353P

Br 50.00

The LF353 is a a high-speed, dual JFET-input operational amplifier (op-amp)IC that uses Junction Field-Effect Transistor as inputs. This IC is providing a high input impedance, Low input bias current, Low noise, Fast response and uses very Low power for working.
Product Type Operational Amplifier
Mount Type Through Hole
Number of Channels 2
Pin Count 8
GBP – Gain Bandwidth Product 3MHz
Minimum Supply Voltage -18V
Maximum Supply Voltage 18V
Input Bias Current 8nA
Input Offset Current 4nA
Vos – Input Offset Voltage 13mV
Slew Rate 13V/μs

LF353P IC JFET DIP-8 Dual Operational Amplifier Chip
Low Input Bias Current (50 pA typical) – Very small current flows into the input pins. Ideal for high-impedance sensors and circuits. Prevents signal distortion.
Low Input Noise Current (0.01 pA/√Hz) – Very little electrical noise added by the op-amp. Useful in audio and precision analog circuits for clean signals.
Low Supply Current (3.6 mA typical) – It draws very little power from the power source. Helps save power in battery-operated or low-power systems.
High Input Impedance (10¹² Ω typical) – Resists drawing current from the signal source. Prevents signal loss, good for voltage follower and sensor applications.
Internally-Trimmed Offset Voltage –Offset voltage is minimized at the factory. Improves accuracy without needing manual tuning.
Gain Bandwidth Product: 3 MHz –It can amplify signals up to 3 million times per second. Suitable for fast or high-frequency signal amplification.
High Slew Rate: 13 V/µs –Output can change rapidly with input changes. Crucial for high-speed applications like audio or analog signals.
